PATCRAFT
5K TILE
All Patcraft running line flooring
products are priced by
" QUOTE REQUEST ONLY "
This style is a "special made only"
product and has a 300 sq. yd.
minimun order requirement.
This product can be custom colored.
5K Modular
Product Specifications
Collection Name Get Up & Go
Style Number I0344
Product Type Modular
Construction Multi-level Pattern Loop
Fiber Type Solution Q Extreme® Nylon
Dye Method 91% Solution Dyed, 9% Yarn Dyed
English Metric
Gauge 1/12 inch 47.2 per 10cm
Stitches Per Inch 10.5 per inch 41 per 10cm
Tufted Pile Height 3/32" low - 6/32" high 2.38mm - 4.76mm
Tufted Yarn Weight 16.0 oz/yd2 542.5 gms/sqm
Finished Pile Thickness 0.079 inches 2.01 mm
Total Thickness 0.235 inches 5.97 mm
Product Size 24.0 X 24.0 inches 61.0 x 61.0 cm
Average Density 7291 per cu.yd. 9.58
Installation Pattern Repeat TILE tile
Primary Backing Non-Woven Synthetic
Secondary Backing EcoWorx® Tile
GSA Approved Product Yes GSA Approved
Performance Specifications
Traffic Class Heavy (TARR)
Antimicrobial Assessment Passes (AATCC-174)
(When installed using Shaw 5036 adhesive)
Methenamine Pill Test Passes (DOCFF-1-70)
Radiant Panel Class I (ASTM E-648)
NBS Smoke Less than 450 (ASTM-E-662)
Electrostatic Propensity Less than 3.5 kV (AATCC-134)
CRI Green Label Plus Certified GLP9968
Warranty Information
Lifetime Commercial Limited
EMAIL TEXAS CARPETS FOR PRICING
ON ALL PATCRAFT FLOORING PRODUCTS!
