PATCRAFT
EDGELAND
All Patcraft running line flooring
products are priced by
" QUOTE REQUEST ONLY "
EdgelandProduct SpecificationsCollection Name Urban ReliefStyle Number I0517Product Type ModularConstruction Multi-level pattern loopFiber Type Solution Q® NylonDye Method 100% Solution Q Nylon English MetricGauge 1/12 47.24 per 10 cmStitches Per Inch 8.5 33.46 per 10 cmTufted Pile Height 6/32" 4.76mmTufted Yarn Weight 17.0 oz 576.40 g/m²Finished Pile Thickness 0.095 2.41 mmTotal Thickness 0.220 5.59 mmProduct Size 24" x 24" 60.96 cm x 60.96 cmAverage Density 6,442 12.00 kilotexSquare Yards per Box 8.89Installation Pattern Repeat noneProtective Treatments SSP® Shaw Soil ProtectionPrimary Backing SyntheticSecondary Backing StrataWorx® TilePerformance SpecificationsTraffic Class Heavy (TARR)Antimicrobial Assessment Passes (AATCC-174)(When installed using Shaw 5036 adhesive)Methenamine Pill Test Passes (DOCFF-1-70)Radiant Panel Class I (ASTM E-648)NBS Smoke Less than 450 (ASTM-E-662)Electrostatic Propensity Less than 3.5 kV (AATCC-134)CRI Green Label Plus Certified GLP 9968ADA Compliance This product meets the guidelines as set forth in the Americans with Disabilities Act for minimum static coefficient of friction of 0.6 for accessible routes.Warranty InformationCarpet Tile 10-year Commercial Limited Warranty for StrataWorx
Edgeland
Product Specifications
Collection Name Urban Relief
Style Number I0517
Product Type Modular
Construction Multi-level pattern loop
Fiber Type Solution Q® Nylon
Dye Method 100% Solution Q Nylon
English Metric
Gauge 1/12 47.24 per 10 cm
Stitches Per Inch 8.5 33.46 per 10 cm
Tufted Pile Height 6/32" 4.76mm
Tufted Yarn Weight 17.0 oz 576.40 g/m²
Finished Pile Thickness 0.095 2.41 mm
Total Thickness 0.220 5.59 mm
Product Size 24" x 24" 60.96 cm x 60.96 cm
Average Density 6,442 12.00 kilotex
Square Yards per Box 8.89
Installation Pattern Repeat none
Protective Treatments SSP® Shaw Soil Protection
Primary Backing Synthetic
Secondary Backing StrataWorx® Tile
Performance Specifications
Traffic Class Heavy (TARR)
Antimicrobial Assessment Passes (AATCC-174)
(When installed using Shaw 5036 adhesive)
Methenamine Pill Test Passes (DOCFF-1-70)
Radiant Panel Class I (ASTM E-648)
NBS Smoke Less than 450 (ASTM-E-662)
Electrostatic Propensity Less than 3.5 kV (AATCC-134)
CRI Green Label Plus Certified GLP 9968
ADA Compliance This product meets the guidelines as set forth in the Americans with Disabilities Act for minimum static
coefficient of friction of 0.6 for accessible routes.
Warranty Information
Carpet Tile 10-year Commercial Limited Warranty for StrataWorx
