PATCRAFT
EDINBURGH
All Patcraft running line flooring
products are priced by
" QUOTE REQUEST ONLY "
EdinburghProduct SpecificationsCollection Name Isle of SkyeStyle Number I0456Product Type ModularConstruction Multi-level Pattern LoopFiber Type Solution Q Extreme® NylonDye Method 100% Solution Dyed English MetricGauge 1/12 47.24 per 10 cmStitches Per Inch 11 43.31 per 10 cmTufted Pile Height 3/32" low - 6/32" high 2.38mm - 4.76mmTufted Yarn Weight 20 oz 678.11 g/m²Total Thickness .220" 5.59 mmProduct Size 12" x 48" 30.48 cm x 121.92 cmAverage Density 8,675 16.15 kilotexInstallation Pattern Repeat TILE tilePrimary Backing Non-Woven SyntheticSecondary Backing EcoWorx® TilePerformance SpecificationsTraffic Class Heavy (TARR)Antimicrobial Assessment Passes (AATCC-174)(When installed using Shaw 5036 adhesive)Methenamine Pill Test Passes (DOCFF-1-70)Stain Resistance Passes (AATCC-175)Radiant Panel Class I (ASTM E-648)NBS Smoke Less than 450 (ASTM-E-662)Electrostatic Propensity Less than 3.5 kV (AATCC-134)CRI Green Label Plus GLP9968ADA Compliance This product meets the guidelines as set forth in the Americans with Disabilities Act for minimum static coefficient of friction of 0.6 for accessible routes.Warranty InformationLifetime Commercial Limited
Edinburgh
Product Specifications
Collection Name Isle of Skye
Style Number I0456
Product Type Modular
Construction Multi-level Pattern Loop
Fiber Type Solution Q Extreme® Nylon
Dye Method 100% Solution Dyed
English Metric
Gauge 1/12 47.24 per 10 cm
Stitches Per Inch 11 43.31 per 10 cm
Tufted Pile Height 3/32" low - 6/32" high 2.38mm - 4.76mm
Tufted Yarn Weight 20 oz 678.11 g/m²
Total Thickness .220" 5.59 mm
Product Size 12" x 48" 30.48 cm x 121.92 cm
Average Density 8,675 16.15 kilotex
Installation Pattern Repeat TILE tile
Primary Backing Non-Woven Synthetic
Secondary Backing EcoWorx® Tile
Performance Specifications
Traffic Class Heavy (TARR)
Antimicrobial Assessment Passes (AATCC-174)
(When installed using Shaw 5036 adhesive)
Methenamine Pill Test Passes (DOCFF-1-70)
Stain Resistance Passes (AATCC-175)
Radiant Panel Class I (ASTM E-648)
NBS Smoke Less than 450 (ASTM-E-662)
Electrostatic Propensity Less than 3.5 kV (AATCC-134)
CRI Green Label Plus GLP9968
ADA Compliance This product meets the guidelines as set forth in the Americans with Disabilities Act for minimum static coefficient of friction of 0.6 for accessible routes.
Warranty Information
Lifetime Commercial Limited
