Skill
Product Specifications
Collection Name Rational
Style Number I0461
Product Type StrataWorx Tile
Construction Multi-Level Pattern Loop
Fiber Type Solution Q® Nylon
Packaging 20 Tiles/Box, 8.88 Sq. Yd. OR 80 Sq. Ft/Box
Dye Method 100% Solution Dyed
Gauge 1/10
Stitches Per Inch 9
Tufted Pile Height 4/32" low - 6/32" high
Tufted Yarn Weight 14.0 oz
Finished Pile Thickness 0.080
Total Thickness 0.249
Product Size 24" x 24"
Average Density 6,300
Square Yards per Box 8.89
Installation Pattern Repeat TILE tile
Protective Treatments SSP® Shaw Soil Protection
Primary Backing Non-Woven Synthetic
Secondary Backing StrataWorx® Tile
Performance Specifications
Traffic Class Heavy (TARR) (TARR)
Antimicrobial Assessment Passes (AATCC-174)
(When installed using Shaw 5036 adhesive)
Methenamine Pill Test Passes (DOCFF-1-70)
Radiant Panel Class I (ASTM E-648)
NBS Smoke < 450 (ASTM-E-662)
Electrostatic Propensity Less than 3.5Kv (AATCC-134)
CRI Green Label Plus GLP8472
ADA Compliance This product meets the guidelines as set forth in the Americans with Disabilities Act for minimum static
coefficient of friction of 0.6 for accessible routes.
Warranty Information
Carpet Tile 10-year Commercial Limited Warranty for StrataWorx
