All Patcraft running line flooring
products are priced by
" QUOTE REQUEST ONLY "
accessProduct SpecificationsCollection Name Walk ForwardStyle Number I0533Product Type ModularConstruction Multi-Level Pattern LoopFiber Type Eco Solution Q® NylonDye Method 100%Solution English MetricGauge 1/12 47.24 per 10 cmStitches Per Inch 10.3 per inch 40.55 per 10 cmTufted Pile Height 6/32" 4.76mmTufted Yarn Weight 26.0 881.55 g/m²Finished Pile Thickness 0.085 2.16 mmTotal Thickness 0.259 6.58 mmProduct Size 24" x 24" 60.96 cm x 60.96 cmAverage Density 11012 20.50 kilotexSquare Yards per Box 5.33Protective Treatments SSP® Shaw Soil ProtectionSecondary Backing EcoWorx® TilePerformance SpecificationsTraffic Class Severe (TARR)Antimicrobial Assessment Passes (AATCC-174)(When installed using Shaw 5036 adhesive)Methenamine Pill Test Passes (DOCFF-1-70)Radiant Panel Class I (ASTM E-648)NBS Smoke Less than 450 (ASTM-E-662)Electrostatic Propensity Less than 3.5 kV (AATCC-134)CRI Green Label Plus Certified GLP 9968ADA Compliance This product meets the guidelines as set forth in the Americans with Disabilities Act for minimum static coefficient of friction of 0.6 for accessible routes.Warranty InformationCarpet Tile Lifetime Commerical Limited Warranty
access
Product Specifications
Collection Name Walk Forward
Style Number I0533
Product Type Modular
Construction Multi-Level Pattern Loop
Fiber Type Eco Solution Q® Nylon
Dye Method 100%Solution
English Metric
Gauge 1/12 47.24 per 10 cm
Stitches Per Inch 10.3 per inch 40.55 per 10 cm
Tufted Pile Height 6/32" 4.76mm
Tufted Yarn Weight 26.0 881.55 g/m²
Finished Pile Thickness 0.085 2.16 mm
Total Thickness 0.259 6.58 mm
Product Size 24" x 24" 60.96 cm x 60.96 cm
Average Density 11012 20.50 kilotex
Square Yards per Box 5.33
Protective Treatments SSP® Shaw Soil Protection
Secondary Backing EcoWorx® Tile
Performance Specifications
Traffic Class Severe (TARR)
Antimicrobial Assessment Passes (AATCC-174)
(When installed using Shaw 5036 adhesive)
Methenamine Pill Test Passes (DOCFF-1-70)
Radiant Panel Class I (ASTM E-648)
NBS Smoke Less than 450 (ASTM-E-662)
Electrostatic Propensity Less than 3.5 kV (AATCC-134)
CRI Green Label Plus Certified GLP 9968
ADA Compliance This product meets the guidelines as set forth in the Americans with Disabilities Act for minimum static
coefficient of friction of 0.6 for accessible routes.
Warranty Information
Carpet Tile Lifetime Commerical Limited Warranty
