PATCRAFT
LETTERPRESS
( WITH SPECIAL )
All Patcraft running line flooring
products are priced by
" QUOTE REQUEST ONLY "
Letterpress PRODUCT SPECIFICATIONSCOLLECTION NAME TypographySTYLE NUMBER I311VCONSTRUCTION LVTWEAR LAYER THICKNESS 20 mil / 020 inches (.5 mm)OVERALL THICKNESS 0.098 inches (2.5 mm)REFERENCE SPECIFICATION Class III printed film vinyl tileASTM F 1700 Type B (embossed)FINISH ExoGuard™INSTALLATION Glue DownRECOMMENDED ADHESIVE Shaw 4100 or S150PackagingPLANK SIZE 23.62 in W x 23.62 in L (60 cm x 60 cm)PIECES /BOX 17SQ FT /BOX 65.88WEIGHT (LB /BOX) 57.9Performance TestingSTATIC LOAD / ASTM F 970 Modified – 2000 psi (lbs/sq in)RESISTANCE TO INDENTATION / ASTM 1914 Passes <8%RESISTANCE TO CHEMICALS / ASTM F925 PassesRADIANT FLUX / ASTM E 648 Class ISMOKE DENSITY / ASTM E 662 <450Warranty15 Year Limited Commercial Warranty. Underbed Warranty Available.
Letterpress PRODUCT SPECIFICATIONS
COLLECTION NAME Typography
STYLE NUMBER I311V
CONSTRUCTION LVT
WEAR LAYER THICKNESS 20 mil / 020 inches (.5 mm)
OVERALL THICKNESS 0.098 inches (2.5 mm)
REFERENCE SPECIFICATION Class III printed film vinyl tile
ASTM F 1700 Type B (embossed)
FINISH ExoGuard™
INSTALLATION Glue Down
RECOMMENDED ADHESIVE Shaw 4100 or S150
Packaging
PLANK SIZE 23.62 in W x 23.62 in L (60 cm x 60 cm)
PIECES /BOX 17
SQ FT /BOX 65.88
WEIGHT (LB /BOX) 57.9
Performance Testing
STATIC LOAD / ASTM F 970 Modified – 2000 psi (lbs/sq in)
RESISTANCE TO INDENTATION / ASTM 1914 Passes <8%
RESISTANCE TO CHEMICALS / ASTM F925 Passes
RADIANT FLUX / ASTM E 648 Class I
SMOKE DENSITY / ASTM E 662 <450
Warranty
15 Year Limited Commercial Warranty. Underbed Warranty Available.
