PATCRAFT
ORGANIC HUE
All Patcraft running line flooring
products are priced by
" QUOTE REQUEST ONLY "
Organic Hue PRODUCT SPECIFICATIONSSTYLE NAME ORGANIC HUESTYLE NUMBER I320VCONSTRUCTION Heterogeneous SheetWEAR LAYER THICKNESS 20 mil / .020 inches (.5 mm)OVERALL THICKNESS 0.086 inches (2.2 mm)REFERENCE SPECIFICATION Type 1, Grade 1ASTM 1303BACKING CLASS 4 ply Fused Backing SystemFINISH ExoGuard™INSTALLATION Glue DownRECOMMENDED ADHESIVE Shaw 4100 or S150PackagingROLL SIZE 72 in W x 25 yd L (50 sy/roll)1.83 m W x 22.86 m LWEIGHT PER ROLL 282.2 lb (128 kg)Performance TestingSTATIC LOAD / ASTM F 970 Modified – 1500 psi (lbs/sq in)RESISTANCE TO INDENTATION / ASTM 1914 Passes <8%RESISTANCE TO CHEMICALS / ASTM F925 PassesRADIANT FLUX / ASTM E 648 Class ISMOKE DENSITY / ASTM E 662 <450Warranty15 Year Limited Commercial Warranty. Underbed Warranty Available.
Organic Hue PRODUCT SPECIFICATIONS
STYLE NAME ORGANIC HUE
STYLE NUMBER I320V
CONSTRUCTION Heterogeneous Sheet
WEAR LAYER THICKNESS 20 mil / .020 inches (.5 mm)
OVERALL THICKNESS 0.086 inches (2.2 mm)
REFERENCE SPECIFICATION Type 1, Grade 1
ASTM 1303
BACKING CLASS 4 ply Fused Backing System
FINISH ExoGuard™
INSTALLATION Glue Down
RECOMMENDED ADHESIVE Shaw 4100 or S150
Packaging
ROLL SIZE 72 in W x 25 yd L (50 sy/roll)
1.83 m W x 22.86 m L
WEIGHT PER ROLL 282.2 lb (128 kg)
Performance Testing
STATIC LOAD / ASTM F 970 Modified – 1500 psi (lbs/sq in)
RESISTANCE TO INDENTATION / ASTM 1914 Passes <8%
RESISTANCE TO CHEMICALS / ASTM F925 Passes
RADIANT FLUX / ASTM E 648 Class I
SMOKE DENSITY / ASTM E 662 <450
Warranty
15 Year Limited Commercial Warranty. Underbed Warranty Available.
EMAIL TEXAS CARPETS FOR PRICINGON ALL PATCRAFT FLOORING PRODUCTS!
