Product Specifications
Product Number 1232202500
Product Construction Tufted Cut & Loop
Yarn System Post-Consumer Content Type 6,6 Nylon
Yarn Manufacturer Universal
Dye Method 100% Solution Dyed
Dye Lots Non-Mergeable
Soil/Stain Protection Protekt²®
Preservative Protection Intersept®
Imperial Metric
Tufted Yarn Weight 23 oz/yd² 780 g/m²
Machine Gauge 5/64 in 50.4 ends/10cm
Pile Height 0.18 in 4.6 mm
Pile Thickness 0.134 in 3.4 mm
Stitches 11.2 /in 43.9 ends/10cm
Pile Density 6,179 oz/yd³ 229.4 g/m³
Size 19.69 in x 19.69 in 50cm x 50cm
Performance Specifications
Flooring Radiant Panel (ASTM E-648) Passes
Smoke Density (ASTM E 662) ≤ 450
Lightfastness (AATCC 16 - E) ≥ 4.0 @ 60 AFU's
Static (AATCC - 134) < 3.0 KV
Dimensional Stability AACHEN Din 54318 <.10%
Traffic Classification Severe
Fiber Modification Ratio 1.7 to 1.9
Preservative Efficacy (AATCC 174 Parts 2&3) 99% Reduction/No Mold 7 Days
(ASTM E-2471) Complete Inhibition
Health + Environmental Specifications
Carbon Footprint 6.58 Kg CO2/M2
Carbon Offsets Carbon Neutral Floors™
Total Recycled Content 67%
Recycled Content (Post Industrial) 65%
Recycled Content (Post Consumer) 2%
Indoor Air Quality Green Label Plus #GLP0820
CDPH 01350
Material Composition Free of Added Formaldehyde, Heavy Metals and Ortho Phthalates, Fluorinated Chemicals (PFAS), and Halogenated Flame Retardants.
Disclosure of Environmental Impacts Environmental Product Declaration
Disclosure of Product Ingredients Health Product Declaration
Environmental Certifications Green Circle Certified Environmental Facts
NSF/ANSI 140 Gold
LEED v4 Contributes to multiple IEQ and MR credits
End of Life Carpet to Carpet Recycling through ReEntry®
Technical Information
Installation See Interface Installation Guidelines online
Maintenance Recommended Interface Maintenance Guidelines
Reclamation Recyclable through ReEntry® - Call 1.888.733.6873 (U.S.) / 1.866.398.3191 (Canada)
Warranty 15 Year Standard Carpet Warranty
Standard Backing GlasBac®
Backing Options (Learn more)
GlasBac®, GlasBac®RE, ReadyBac™, CushionBac Renew™
Tile Size Options
50cm x 50cm
Manufacturing Location ISO 9001 & 14001 Certified facilities in Troup County, Georgia, United States
